Display Type |
24° field-of-view, 24-bit color LCD, 0.35-inch diagonal, outdoor visible |
Resolution |
HD (1280X720) |
PPE Compatibility |
Works with many hard hats, protective eyewear, masks and more |
Microphone |
4 digital microphones with active noise cancellation Accurate voice recognition in noise up to 100 dBA |
Speaker |
Internal 94 dBA loudspeaker |
Camera Image |
48 MP Sensor, PDAF with LED flashlight |
Camera Video |
Up to 1080p @ 60fps, >6X zoom in HD, video stabilization. codecs: VP8, VP9, H.264, H.265 HEVC |
Warranty |
1-Year Warranty |
Extended Service & Support Plans |
Available |
Foresight Cloud Services |
Accelerates centralized deployment and management of devices |
Included accessories
|
Workband, USB Type-C charging cable
|
Security |
Qualcomm® Trusted Execution Environment, Crypto Engine, Secure Boot |
Operating System
|
Android 11 (AOSP) + WearHF™ hands-free interface + Enterprise features |
Chipset |
2.0 GHz 8-core Qualcomm® Snapdragon™ 662 with Adreno 610 GPU - OpenGL® ES 3.2 & OpenCL™ 2.0 |
Memory |
64GB internal storage / 4GB RAM / MicroSD slot (max card supported 512GB) |
Languages & Dialects Supported |
Chinese (Cantonese, Mandarin-Simplified and Traditional), Czech, Dutch, English (American, Australian, British), French, German, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Thai |
Bluetooth |
Bluetooth® 5.1 |
Wi-Fi |
802.11 a/b/g/n/ac - 2.4 GHz and 5GHz |
GPS and Location |
• GPS, Glonass, BeiDou, Galileo, QZSS, and SBAS • NavIC support • Dual-Frequency GNSS (L1 + L5) • Qualcomm® Sensor-Assisted Positioning |
IMU - Head Movement Tracking |
3 IMUs (including 3-axis accelerometers, gyroscopes, eCompass) |
Capacity |
2,600 mAh / 10.0 Wh Li-polymer, rechargeable, hot-swappable |
Weight |
9.7oz/274g |
Ruggedization |
IP66, MIL-STD-810H, 6.5 feet / 2-meter drop |
Dedicated Buttons |
Power button (with integrated fingerprint sensor), Programmable: action button, left button, right button |
Ports |
1/8” / 3.5mm audio, 1 USB Type-C |
Boom Arm |
Adjusts six ways for most head sizes, left or right eye compatible, display can be moved out of way when not in use |
Operating Temperature, Humidity |
-4°F to +122°F / -20°C to +50°C, 5% to 95% relative humidity (non-condensing) |
Included Applications |
Document Navigator, Camera with Barcode Reader, Audio Recorder, Video Recorder, Webpage Viewer, Cloud Sync, Media Player, Calculator, Pedometer, Timer |
Sign-in Options |
Companion App, Voice Keyboard with secure mode |
